Dimensions - Structural Tees cut from UBs
Welcome to our Structural Tees cut from UBs dimensions page! Here you'll find dimensions for all UK Structural Tees cut from UBs steel sections described by the Steelwork Design Guide to BS5950-1:2000, Volume 1, Section Properties, Member Capacities, 7th Edition (also known as The Blue Book). Sort the table below according to any property and select a CAD file to download using the reference links in the left-most column.
You can also purchase all our CAD data in one easy download, containing the shapes as individual files or AutoCAD Design Center files! Click here to visit our Shop.
| Section Reference | Cut from Universal Beam | Mass per Metre | Width of Section | Depth of Section | Thickness | Root Radius | Ratios for Local Buckling | Dimension | Second Moment of Area | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Web | Flange | Flange | Web | Axis x-x | Axis y-y | |||||||
| kg/m | B mm | d mm | t mm | T mm | r mm | b/T | d/t | Cx | cm4 | cm4 | ||
| 305x457x127 | 914x305x253 | 126.7 | 305.5 | 459.1 | 17.3 | 27.9 | 19.1 | 5.47 | 26.5 | 12 | 32700 | 6650 |
| 305x457x112 | 914x305x224 | 112.1 | 304.1 | 455.1 | 15.9 | 23.9 | 19.1 | 6.36 | 28.6 | 12.1 | 29100 | 5620 |
| 305x457x101 | 914x305x201 | 100.4 | 303.3 | 451.4 | 15.1 | 20.2 | 19.1 | 7.51 | 29.9 | 12.5 | 26400 | 4710 |
| 292x419x113 | 838x292x226 | 113.3 | 293.8 | 425.4 | 16.1 | 26.8 | 17.8 | 5.48 | 26.4 | 10.8 | 24600 | 5680 |
| 292x419x97 | 838x292x194 | 96.9 | 292.4 | 420.3 | 14.7 | 21.7 | 17.8 | 6.74 | 28.6 | 11.1 | 21300 | 4530 |
| 292x419x88 | 838x292x176 | 87.9 | 291.7 | 417.4 | 14 | 18.8 | 17.8 | 7.76 | 29.8 | 11.4 | 19600 | 3900 |
| 267x381x99 | 762x267x197 | 98.4 | 268 | 384.8 | 15.6 | 25.4 | 16.5 | 5.28 | 24.7 | 9.89 | 17500 | 4090 |
| 267x381x87 | 762x267x173 | 86.5 | 266.7 | 381 | 14.3 | 21.6 | 16.5 | 6.17 | 26.6 | 9.98 | 15500 | 3430 |
| 267x381x74 | 762x267x147 | 73.5 | 265.2 | 376.9 | 12.8 | 17.5 | 16.5 | 7.58 | 29.4 | 10.2 | 13200 | 2730 |
| 267x381x67 | 762x267x134 | 66.9 | 264.4 | 374.9 | 12 | 15.5 | 16.5 | 8.53 | 31.2 | 10.3 | 12100 | 2390 |
| 254x343x85 | 686x254x170 | 85.1 | 255.8 | 346.4 | 14.5 | 23.7 | 15.2 | 5.4 | 23.9 | 8.67 | 12100 | 3320 |
| 254x343x76 | 686x254x152 | 76.2 | 254.5 | 343.7 | 13.2 | 21 | 15.2 | 6.06 | 26 | 8.61 | 10800 | 2890 |
| 254x343x70 | 686x254x140 | 70 | 253.7 | 341.7 | 12.4 | 19 | 15.2 | 6.68 | 27.6 | 8.63 | 9910 | 2590 |
| 254x343x63 | 686x254x125 | 62.6 | 253 | 338.9 | 11.7 | 16.2 | 15.2 | 7.81 | 29 | 8.85 | 8980 | 2190 |
| 305x305x119 | 610x305x238 | 119 | 311.4 | 317.9 | 18.4 | 31.4 | 16.5 | 4.96 | 17.3 | 7.11 | 12400 | 7920 |
| 305x305x90 | 610x305x179 | 89.5 | 307.1 | 310 | 14.1 | 23.6 | 16.5 | 6.51 | 22 | 6.69 | 9040 | 5700 |
| 305x305x75 | 610x305x149 | 74.6 | 304.8 | 306.1 | 11.8 | 19.7 | 16.5 | 7.74 | 25.9 | 6.45 | 7410 | 4650 |
| 229x305x70 | 610x229x140 | 69.9 | 230.2 | 308.5 | 13.1 | 22.1 | 12.7 | 5.21 | 23.5 | 7.61 | 7740 | 2250 |
| 229x305x63 | 610x229x125 | 62.5 | 229 | 306 | 11.9 | 19.6 | 12.7 | 5.84 | 25.7 | 7.54 | 6900 | 1970 |
| 229x305x57 | 610x229x113 | 56.5 | 228.2 | 303.7 | 11.1 | 17.3 | 12.7 | 6.6 | 27.4 | 7.58 | 6270 | 1720 |
| 229x305x51 | 610x229x101 | 50.6 | 227.6 | 301.2 | 10.5 | 14.8 | 12.7 | 7.69 | 28.7 | 7.78 | 5690 | 1460 |
| 178x305x50 | 610x178x100 | 50.1 | 179.2 | 303.7 | 11.3 | 17.2 | 12.7 | 5.21 | 26.9 | 8.57 | 5890 | 829 |
| 178x305x46 | 610x178x92 | 46.1 | 178.8 | 301.5 | 10.9 | 15 | 12.7 | 5.96 | 27.7 | 8.78 | 5450 | 718 |
| 178x305x41 | 610x178x82 | 40.9 | 177.9 | 299.3 | 10 | 12.8 | 12.7 | 6.95 | 29.9 | 8.88 | 4840 | 603 |
| 312x267x136 | 533x312x272 | 136.6 | 320.2 | 288.8 | 21.1 | 37.6 | 12.7 | 4.26 | 13.7 | 6.28 | 10600 | 10300 |
| 312x267x110 | 533x312x219 | 109.4 | 317.4 | 280.4 | 18.3 | 29.2 | 12.7 | 5.43 | 15.3 | 6.09 | 8530 | 7790 |
| 312x267x91 | 533x312x182 | 90.7 | 314.5 | 275.6 | 15.2 | 24.4 | 12.7 | 6.44 | 18.1 | 5.78 | 6890 | 6330 |
| 312x267x75 | 533x312x151 | 75.3 | 312 | 271.5 | 12.7 | 20.3 | 12.7 | 7.68 | 21.4 | 5.54 | 5620 | 5140 |
| 210x267x69 | 533x210x138 | 69.1 | 213.9 | 274.5 | 14.7 | 23.6 | 12.7 | 4.53 | 18.7 | 6.94 | 5990 | 1930 |
| 210x267x61 | 533x210x122 | 61 | 211.9 | 272.2 | 12.7 | 21.3 | 12.7 | 4.97 | 21.4 | 6.66 | 5160 | 1690 |
| 210x267x55 | 533x210x109 | 54.5 | 210.8 | 269.7 | 11.6 | 18.8 | 12.7 | 5.61 | 23.3 | 6.61 | 4600 | 1470 |
| 210x267x51 | 533x210x101 | 50.5 | 210 | 268.3 | 10.8 | 17.4 | 12.7 | 6.03 | 24.8 | 6.53 | 4250 | 1350 |
| 210x267x46 | 533x210x92 | 46 | 209.3 | 266.5 | 10.1 | 15.6 | 12.7 | 6.71 | 26.4 | 6.55 | 3880 | 1190 |
| 210x267x41 | 533x210x82 | 41.1 | 208.8 | 264.1 | 9.6 | 13.2 | 12.7 | 7.91 | 27.5 | 6.75 | 3530 | 1000 |
| 165x267x43 | 533x165x85 | 42.3 | 166.5 | 267.1 | 10.3 | 16.5 | 12.7 | 5.05 | 25.9 | 7.23 | 3750 | 637 |
| 165x267x37 | 533x165x75 | 37.3 | 165.9 | 264.5 | 9.7 | 13.6 | 12.7 | 6.1 | 27.3 | 7.46 | 3350 | 520 |
| 165x267x33 | 533x165x66 | 32.8 | 165.1 | 262.4 | 8.9 | 11.4 | 12.7 | 7.24 | 29.5 | 7.59 | 2960 | 429 |
| 191x229x81 | 457x191x161 | 80.7 | 199.4 | 246 | 18 | 32 | 10.2 | 3.12 | 13.7 | 6.22 | 5160 | 2130 |
| 191x229x67 | 457x191x133 | 66.6 | 196.7 | 240.3 | 15.3 | 26.3 | 10.2 | 3.74 | 15.7 | 5.96 | 4180 | 1670 |
| 191x229x53 | 457x191x106 | 52.9 | 194 | 234.6 | 12.6 | 20.6 | 10.2 | 4.71 | 18.6 | 5.73 | 3260 | 1260 |
| 191x229x49 | 457x191x98 | 49.1 | 192.8 | 233.5 | 11.4 | 19.6 | 10.2 | 4.92 | 20.5 | 5.53 | 2970 | 1170 |
| 191x229x45 | 457x191x89 | 44.6 | 191.9 | 231.6 | 10.5 | 17.7 | 10.2 | 5.42 | 22.1 | 5.47 | 2680 | 1040 |
| 191x229x41 | 457x191x82 | 41 | 191.3 | 229.9 | 9.9 | 16 | 10.2 | 5.98 | 23.2 | 5.47 | 2470 | 935 |
| 191x229x37 | 457x191x74 | 37.1 | 190.4 | 228.4 | 9 | 14.5 | 10.2 | 6.57 | 25.4 | 5.38 | 2220 | 836 |
| 191x229x34 | 457x191x67 | 33.5 | 189.9 | 226.6 | 8.5 | 12.7 | 10.2 | 7.48 | 26.7 | 5.46 | 2030 | 726 |
| 152x229x41 | 457x152x82 | 41 | 155.3 | 232.8 | 10.5 | 18.9 | 10.2 | 4.11 | 22.2 | 5.96 | 2600 | 592 |
| 152x229x37 | 457x152x74 | 37.1 | 154.4 | 230.9 | 9.6 | 17 | 10.2 | 4.54 | 24.1 | 5.88 | 2330 | 523 |
| 152x229x34 | 457x152x67 | 33.6 | 153.8 | 228.9 | 9 | 15 | 10.2 | 5.13 | 25.4 | 5.91 | 2120 | 456 |
| 152x229x30 | 457x152x60 | 29.9 | 152.9 | 227.2 | 8.1 | 13.3 | 10.2 | 5.75 | 28 | 5.84 | 1880 | 397 |
| 152x229x26 | 457x152x52 | 26.1 | 152.4 | 224.8 | 7.6 | 10.9 | 10.2 | 6.99 | 29.6 | 6.04 | 1670 | 322 |
| 178x203x43 | 406x178x85 | 42.6 | 181.9 | 208.6 | 10.9 | 18.2 | 10.2 | 5 | 19.1 | 4.91 | 2030 | 915 |
| 178x203x37 | 406x178x74 | 37.1 | 179.5 | 206.3 | 9.5 | 16 | 10.2 | 5.61 | 21.7 | 4.76 | 1740 | 773 |
| 178x203x34 | 406x178x67 | 33.5 | 178.8 | 204.6 | 8.8 | 14.3 | 10.2 | 6.25 | 23.3 | 4.73 | 1570 | 682 |
| 178x203x30 | 406x178x60 | 30 | 177.9 | 203.1 | 7.9 | 12.8 | 10.2 | 6.95 | 25.7 | 4.64 | 1400 | 602 |
| 178x203x27 | 406x178x54 | 27 | 177.7 | 201.2 | 7.7 | 10.9 | 10.2 | 8.15 | 26.1 | 4.83 | 1290 | 511 |
| 140x203x27 | 406x140x53 | 26.6 | 143.3 | 203.3 | 7.9 | 12.9 | 10.2 | 5.55 | 25.7 | 5.16 | 1320 | 317 |
| 140x203x23 | 406x140x46 | 23 | 142.2 | 201.5 | 6.8 | 11.2 | 10.2 | 6.35 | 29.6 | 5.02 | 1120 | 269 |
| 140x203x20 | 406x140x39 | 19.5 | 141.8 | 198.9 | 6.4 | 8.6 | 10.2 | 8.24 | 31.1 | 5.32 | 979 | 205 |
| 171x178x34 | 356x171x67 | 33.5 | 173.2 | 181.6 | 9.1 | 15.7 | 10.2 | 5.52 | 20 | 4 | 1150 | 681 |
| 171x178x29 | 356x171x57 | 28.5 | 172.2 | 178.9 | 8.1 | 13 | 10.2 | 6.62 | 22.1 | 3.97 | 986 | 554 |
| 171x178x26 | 356x171x51 | 25.5 | 171.5 | 177.4 | 7.4 | 11.5 | 10.2 | 7.46 | 24 | 3.94 | 882 | 484 |
| 171x178x23 | 356x171x45 | 22.5 | 171.1 | 175.6 | 7 | 9.7 | 10.2 | 8.82 | 25.1 | 4.05 | 798 | 406 |
| 127x178x20 | 356x127x39 | 19.5 | 126 | 176.6 | 6.6 | 10.7 | 10.2 | 5.89 | 26.8 | 4.43 | 728 | 179 |
| 127x178x17 | 356x127x33 | 16.5 | 125.4 | 174.4 | 6 | 8.5 | 10.2 | 7.38 | 29.1 | 4.56 | 626 | 140 |
| 165x152x27 | 305x165x54 | 27 | 166.9 | 155.1 | 7.9 | 13.7 | 8.9 | 6.09 | 19.6 | 3.21 | 642 | 531 |
| 165x152x23 | 305x165x46 | 23 | 165.7 | 153.2 | 6.7 | 11.8 | 8.9 | 7.02 | 22.9 | 3.07 | 536 | 448 |
| 165x152x20 | 305x165x40 | 20.1 | 165 | 151.6 | 6 | 10.2 | 8.9 | 8.09 | 25.3 | 3.03 | 468 | 382 |
| 127x152x24 | 305x127x48 | 24 | 125.3 | 155.4 | 9 | 14 | 8.9 | 4.48 | 17.3 | 3.94 | 662 | 231 |
| 127x152x21 | 305x127x42 | 20.9 | 124.3 | 153.5 | 8 | 12.1 | 8.9 | 5.14 | 19.2 | 3.87 | 573 | 194 |
| 127x152x19 | 305x127x37 | 18.5 | 123.4 | 152.1 | 7.1 | 10.7 | 8.9 | 5.77 | 21.4 | 3.78 | 501 | 168 |
| 102x152x17 | 305x102x33 | 16.4 | 102.4 | 156.3 | 6.6 | 10.8 | 7.6 | 4.74 | 23.7 | 4.14 | 487 | 97.1 |
| 102x152x14 | 305x102x28 | 14.1 | 101.8 | 154.3 | 6 | 8.8 | 7.6 | 5.78 | 25.7 | 4.2 | 420 | 77.7 |
| 102x152x13 | 305x102x25 | 12.4 | 101.6 | 152.5 | 5.8 | 7 | 7.6 | 7.26 | 26.3 | 4.43 | 377 | 61.5 |
| 146x127x22 | 254x146x43 | 21.5 | 147.3 | 129.7 | 7.2 | 12.7 | 7.6 | 5.8 | 18 | 2.64 | 343 | 339 |
| 146x127x19 | 254x146x37 | 18.5 | 146.4 | 127.9 | 6.3 | 10.9 | 7.6 | 6.72 | 20.3 | 2.55 | 292 | 285 |
| 146x127x16 | 254x146x31 | 15.5 | 146.1 | 125.6 | 6 | 8.6 | 7.6 | 8.49 | 20.9 | 2.66 | 259 | 224 |
| 102x127x14 | 254x102x28 | 14.1 | 102.2 | 130.1 | 6.3 | 10 | 7.6 | 5.11 | 20.7 | 3.24 | 277 | 89.3 |
| 102x127x13 | 254x102x25 | 12.6 | 101.9 | 128.5 | 6 | 8.4 | 7.6 | 6.07 | 21.4 | 3.32 | 250 | 74.3 |
| 102x127x11 | 254x102x22 | 11 | 101.6 | 126.9 | 5.7 | 6.8 | 7.6 | 7.47 | 22.3 | 3.45 | 223 | 59.7 |
| 133x102x15 | 203x133x30 | 15 | 133.9 | 103.3 | 6.4 | 9.6 | 7.6 | 6.97 | 16.1 | 2.11 | 154 | 192 |
| 133x102x13 | 203x133x25 | 12.5 | 133.2 | 101.5 | 5.7 | 7.8 | 7.6 | 8.54 | 17.8 | 2.1 | 131 | 154 |
